P528

卡片终端

基于瑞芯微RK3528平台，具有极小设计，入网便捷，广泛应用于窗口企业、政务、教育、办公、金融等云电脑场景。

留言咨询业务咨询

规格参数

CPU	CPU	RK3528，4 Core A53, 2.0GHz
CPU	NPU	N/A
Display	Graphic card	Mali-450 MP2
	Multi displays	N/A
	Interface	1 x HDMI-Out 4K @60Hz
Network	Lan Interface	100Mbps
	Lan Connector	1 x RJ45 Ports
	Wireless Type	SDIO
	Wireless Interface	2T2R, 2.4G/5G WiFi5 /BT4.2
	4G/5G	N/A
I/O interface	Serial Port	N/A
	USB	1 x USB3.0, 2 x USB2.0
	Button	1 x Power Button
	SIM CARD	N/A
	AUDIO	1 x 3.5mm Audio Jack（Mic-In + Line Out）
	POWER	1 x Type-C (Charging Port)
System	Memory	2GB LPDDR4/4X, Optional 4GB
	Storage	16GB EMMC, Optional 32GB
	OS	Android 9 / Linux
	MCU	Optional (Wake-on-LAN /Remote Shutdown /Watchdog /Auto Power On)
	RTC	Power on at specific time everyday
	Other	Optional IR
	Power Input	5v DC-In (Type-C)
	Dimension	108mm(L) x 67mm(W) x 18mm(H)
	Operating Temp.	0~45℃
	Operating Humidity	10%~90% non-condensing
	Storage Temp	-20~70℃
	Operating Humidity	5%~90% non-condensing
