CPU | CPU | Intel 12th/13/14th Core i3/Core i5 /Core i7/Pentium/Celeron |
TDP | ≤65W | |
Display | Graphic card | Intergrated |
Multi displays | Support Two or Three displays | |
Interface | 1 x HDMI-Out 4K @30Hz | |
Network | Lan IC | 1 x LAN IC |
Lan Interface | 10/100/1000Mbps | |
Lan Connector | 1 x RJ45 Ports | |
Wireless Type | M.2 Key E 2230 Module | |
Wireless Interface | Mini PCIe WiFi/BT Module, Intel 3165/ Intel AX101/Intel AX210 | |
4G/5G | Not Support | |
I/O interface | Serial Port | 1 x RS232 COM or 1x VGA(Option) |
USB | 4 x USB3.0A | |
Button | 1 x PowerButton, 2x USB3.0*2,1xcombo 1xUSB2.0C (PD 18W) | |
SIM CARD | Not Support | |
AUDIO | 1 x Line Out ; 1 x MIC-In | |
POWER | 1 x 2.5/5.5 DC-IN Connector | |
System | Memory | Dual SoDIMM DDR4 Max. 64 GB |
Storage | 1 x M.2 Key M 2280 Size For NVMe/SATA SSD | |
OS | Window11 | |
WatchDog | Not Support | |
Auto Power On | Yes | |
RTC | Power on at specific time everyday | |
Power Input | 12-19v 2.5/5.5 DC-In | |
Dimension | L615 x H554 x W141mm | |
Operating Temp. | 0~40℃ | |
Operating Humidity | 10%~90% non-condensing | |
Storage Temp | -20~70℃ | |
Operating Humidity | 5%~95% non-condensing |
