K115F

X86 平台商显终端

基于英特尔Raptor Lake-U平台设计，处理器采用E+P混合技术架构，具有英特尔Vpro技术和TPM2.0功能，可提供远程管理和数据安全性。是理想的数字标牌、自主设备以及信息发布系统的硬件解决方案

•: 1 x DP 8K@60Hz, 1 x Type-C 4K@60Hz 显示输出；支持 WIFI6, 1 x 2.5Gbps 网口，1 x 千兆网口 2 x USB3.2 Gen2, 2 x USB2.0, 1 x USB3.2 Gen1, 1 x Type-C，2 x RS232 COM

留言咨询业务咨询

规格参数

CPU	CPU	Intel® Core™ Processor I3/I5/I7
CPU	TDP	15 W
Display	Graphic card	Intel® Iris® Xe Graphics
	Multi displays	Support quad display
	Interface	2 x HDMI-out 4K@60Hz (HDMI 1 support HDMI CEC, optional)
	Interface	1 x DP 8K@60Hz, 1 x Type-C 4K@60Hz
System	Memory	Dual SoDIMM DDR4 Max. 32 GB
	Storage	1 x M.2 Key M 2280 NVMe SSD
	Storage	1 x M.2 Key M 2280 SATA SSD
	OS	Window11/Windows10/Linux
	WatchDog	Support
	Auto Power On	Yes
	RTC	Power on at specific time everyday
	Power Input	12-19V 2.5/5.5 DC-In
	Dimension	210mm(L) x 149mm(W) x 23mm(H)
	Operating Temp.	-5~45℃
	Operating Humidity	10%~90% non-condensing
	Storage Temp.	-20~70℃
	Storage Humidity	5%~95% non-condensing
Network	Lan IC	2 x LAN IC
	Lan Interface	10/100/1000Mbps/2.5Gbps
	Lan Connector	2 x RJ45 Ports
	Wireless Type	M.2 Key E 2230 Module
	Wireless Interface	WiFi/BT Module
	Wireless Interface	Intel AX101
I/O interface	Serial Port	1 x COM1 (RS232/RS485)
	Serial Port	1 x COM2 (RS232/RS485)
	USB	2 x USB3.2 Gen2 Type-A
		1 x Type-C (USB3.2 Gen1)
		1 x USB2.0, 1 x USB3.2 Gen1 Type-A
	Button	1 x Power Button, 1 x Reset Button
	Audio	1 x Line-out, 1 x Mic-in
	Power	1 x 2.5/5.5 DC-IN
